VIR50 Dual Laser IR Video Thermometer
Brand: ExtechThe IRT600 is a Dual Laser IR Thermal Condensation Scanner.
This 12:1 Infrared Psychrometer with 3-Color LED Dew Point Alarm measures temperature and humidity then calculates Dew Point and warns the user when conditions for mold growth exist.
Great for processes that require surface temperature control and monitoring. Green LED changes to Yellow and then to Red as the surface temperature reading gets closer to and then equals the calculated Dew Point reading.
Dual lasers indicate ideal measuring distance where the two lasers converge to a 1" target spot.
Complete with case and 9V battery.
Features- Non-contact IR Temperature measurement from -58 to 3992°F (-50 to 2200°C) with 50:1 distance to target ratio.
- Built-in VGA (640 x 480) Camera.
- MicroSD card for capturing images (JPEG) and video (3GP) for viewing on your PC.
- Dual laser indicates ideal measuring distance where the two laser points converge to a 1" target spot.
- Fast 150 millisecond response time, color LED bar graph for viewing trends.
- Type K Thermocouple input, USB interface.
- Air Temperature and Relative Humidity measurement.
- Adjustable emissivity increases measurement accuracy for different surfaces.
- Adjustable High/Low set points with audible alarm alerts user when temperature exceeds the programmed set points.
- MAX/MIN/AVG/DIF functions, Auto Power Off.
- Complete with microSD card, general-purpose Type K bead wire probe, USB cable, rechargeable 3.7V battery, and carrying case.
Specifications
Brand
Air Temperature Range
- 32° to 122° F (0° to 50° C)
Basic Accuracy
- ± (1 % of Reading + 4° F/2° C) (31° to 212° F)
Camera
- 640 x 480 Pixels
Dimensions
- 7.4 x 6.0 x 2.2” (189 x 152 x 57 mm)
Emissivity
- 0.10 to 1.00 Adjustable
Field of View (Distance to Target)
- 50:1
IR Temperature Range
- -58° to 3992° F (-50° to 2200° C)
Laser Convergence Distance
- 50” (127 cm)
LCD Display
- 2.2” TFT 320 x 240 Pixels
Maximum Resolution
- 0.1° F/°C
Relative Humidity
- 0 to 100 % Relative Humidity
Repeatability
- ± 0.5 % or 1.8° F / 1° C
Type K Temperature Range
- -58° to 2498° F (-50° to 1370° C)
Weight
- 17.4 oz. (494 g)
